50kW AC DC Converter Module Features
● Support function customization
● Adopting three-level topology, the maximum efficiency can reach 98.5%, the power quality is better
● Supporting constant current, constant power, MPPT, AC voltage source control, with black start function
● Standard rack-mounted modular design, flexible configuration, convenient maintenance, convenient expansion
● Three-phase three-wire, high voltage utilization, flexible battery configuration, adaptable to a variety of batteries including lithium battery/lead acid/photovoltaic module/DC bus
● Adopting patented harmonic suppression technology, it is suitable for diversified scenarios such as industrial parks and micro-grids. It is suitable for 52s Pack and can meet various battery pack requirements modular design
50kW AC DC Converter Module
Certifications:
IEC50549;IEC62109;IEC61000;IEC61683;IEC60068;IEC62477;EN62477;IEC61727;IEC62116;NRS097
50kW AC DC Converter Module Parameters
Model:
Rated Power:
Maximum power:
DC working voltage range:
Full-load voltage range on the DC side:
Maximum DC current:
Rated AC voltage:
Rated frequency:
Rated AC current:
Overload capacity :
Current distortion :
Power factor adjustment range:
Adapt to the battery:
Charging method:
Work mode:
Maximal efficiency:
Dimensions (W*D*H):
Weight (approx):
Isolation method:
Anti-corrosion grade:
Applied environmental protection grade:
Levels of protection:
Working temperature：
Cooling method：
Noise：
Altitude：
Communication interface：
HT-50 AC
50kW
55kW
590V~1000V
500V~950V (AC 400 Vac corresponding to DC voltage>580V)
92A
400Vac ，3W+PE
50/60Hz(±5Hz)
72A
110%,normal operation;120%,1 minute
<3% (rated power)
-1 advance~+1 lag
Lithium/lead acid/pv module/DC busbar
Depend on the BMS instruction / three-stage / MPPT
Constant current constant power, MPPT,and the AC voltage source
98.5%
483 (excluding mounting lug 440) * 600 * 150mm
35kg
Non-isolation
C3
The module is built in the IP55 outdoor cabinet
IP65 optional
0~95% (non-condensation)
Intelligent air cooling
＜75dB
3000m ( > 3000m drop)
CAN
50kW AC DC Converter Module Application Scenario
In a multi-energy complementary power supply system including photovoltaics, wind power, diesel engines or public power grids, the power balance and stable operation control of the microgrid system can be achieved through the supporting energy storage system. It is suitable for islands, mountainous areas, border outposts and other remote areas or areas with unstable power supply, and is also suitable for the energy optimization system of photovoltaic storage and charging in newly built science and technology parks.
◎Peak shaving and valley filling + Reverse flow prevention + Demand control
Automatic charging and discharging according to time-of-use electricity prices Monitoring distribution capacity and load
◎Backup power supply + Seamless switching
Adjustment of anti-islanding protection strategy, optional STS power module Seamless switching between on-grid and off-grid, UPS type energy storage, uninterrupted power supply
◎Off-grid power supply + Impact load
To meet the needs of microgrid or off-grid operation with impact load Reserved photovoltaic interface; compatible with diesel engine access
◎Off-grid power supply + Impact load
Photovoltaic + Energy storage, high energy storage ratio
AC-DC dual busbar, Photovoltaic DC side coupling
For more information about DC DC modules, please refer to
For more information about STS modules, please refer to
For more energy storage batteries, please refer to
HT 50kW AC DC Power Module Product Details
FREQUENTLY ASKED QUESTIONS
─── About 50kW AC DC Converter Module ───
Maximum conversion efficiency 99%
The maximum supported power output is 110%, 55kW for long-term operation, and 60kW for 10 minutes
Yes, the 50kW AC DC converter module supports access to the photovoltaic system and can output a standard 400V voltage to power the load
Yes, our 50kW AC DC converter module supports function customization, welcome to consult
Our 50kw AC DC converter module has been listed in Belgium, Netherlands, South Africa, Hungary, Thailand, UK, Italy, Poland. More countries are in progress. Please consult our sales staff for your country's listing
